At Jianghe, we are dedicated to manufacturing world-leading telehandlers! The Jianghe-branded telehandler officially launched in 2017. Since then, Jianghe has adhered to the principles of positive values, top-tier performance and high reliability for earning wide-spread market recognition.
From structural design to safety protection, every detail is carefully engineered.
The main girder uses a high-quality carbon steel welded box structure with high rigidity and strong load capacity. Optimized by FEA to remain stable under long-term heavy loads.
Equipped with overload limiters, limit switches, buffers and multiple safety devices. The electromagnet retains magnetism during power loss to keep loads secure.
Supports floor, cabin and remote control. Modular parts with high interchangeability for easier service and lower operating costs.
Widely used in steel metallurgy, shipbuilding, ports and scrap handling. Flexible electromagnet configurations for different working conditions.
Three core mechanisms work together, with multiple configuration options for different working conditions.
Standard model parameters below; customization available for actual working conditions.
| Parameter | Standard | Optional range | Unit |
|---|---|---|---|
| Standard Rated Lifting Capacity | 10 | 1 - 20 | t |
| Standard Span | 22.5 | 7.5 - 28.5 | m |
| Lifting height | 6 - 30 | 6 - 30 | m |
| Standard Trolley Travelling Speed | 25 | 10 - 40 | m/min |
| Standard Crane Travelling Speed | 70 | 20 - 100 | m/min |
| Standard Duty Class | A5 | A4 - A6 | — |
| Standard Power Supply Voltage | 380V / 50Hz | Customizable | V/Hz |
| Standard Operation Mode | Remote | Floor / Remote | — |
| Standard Total Weight | ≈ 2.8 | Varies by model | t |
From Korea to Vietnam, Ukraine to China, Xinjianghe electromagnetic bridge cranes serve customers worldwide.
Custom A6-duty electromagnetic bridge crane for Samsung Heavy Industries shipyard, used for hull plate handling and assembly.
Spreader-beam attachment exported to a major Vietnam steel mill for billet handling and stacking.
Designed for a Hebei steel mill; processes over 1,000 tons of billets daily with stable operation.
Ukraine export project adapted for extreme cold and international standards.
Upper rotation for 360° lifting, meeting flexible operations at a Shaanxi steel mill.
Whether standard or custom, we deliver optimal electromagnetic lifting solutions.
